Visualise Your Building

With the newest zencontrols ‘Plan View’ technology facility managers, maintenance personnel, and other stakeholders can quickly and easily visualise your site.

Plan View Technology 750x260 - Visualise + Interact With Your Building
Plan View Online 800x - Visualise + Interact With Your Building

Plan View

zencontrols Plan View allows you to visualise the building from the plan and easily see faults and issues.

The basic version of Plan View is free with your zencontrol system, with the ability to upgrade to include heat mapping and other visualisations.

Plan View can be accessed from a web browser on your PC or from Android or Apple Tablets.

Features of Plan View

Perhaps you require power metering?

Features that zencontrols Plan View can provide:

  • Visualisation from building plans
  • Easy identification of faults/failures
  • Heatmaps for various datasets
  • Supports multiple users
  • Group and controller selection tools
  • Supports real-time or periodic updates
  • Ability to filter/view selected types of devices
  • Supports Android and Apple tablets or PC/MAC
  • Can zoom in/out of high res vector plans
  • Analyses power consumption of DALI lines
  • Ability to view different data such as battery levels, arc levels, etc
  • Automatic background tiling of plan to load only data required
  • Fittings, switches, sensors can be grouped with the selection tool
  • Multiple icon sizes and resolutions supported based on user or site preferences
Planview Tablet - Visualise + Interact With Your Building

Past Projects

View all projects >
Warehouse lighting control Patiki 600x450 - Visualise + Interact With Your Building

Warehouse Lighting Control

This new warehousing facility on Patiki Road, Avondale comprises five warehouses. The warehouse lighting control system comprises C-Bus relays installed in local distribution boards. Touchscreens in each building provide a graphical interface to allow easy scheduling of the lighting, and manual control ...
